Product description：
The DT-NSCB adopts a high-performance super-second-generation image intensifier, and the special post-aiming device is designed, the aiming effect at night is good, the structure adopts a full-metal body, the mechanical strength is high, the structure is small, and the structure is easy to assemble and disassemble. And the white light aiming device is matched with the white light aiming device, so that a good viewing effect can be achieved at night.
Technical specifications:
| MODEL |
DT-NSCB1 |
DT-NSCB3 |
| Generation |
Gen 2+/Gen3(optional) |
Gen 2+/Gen3(optional) |
| Magnification |
1X |
2X |
| Resolution |
60-64 |
60-64 |
| Objective pupil |
22mm |
40mm |
| FOV(°) |
40 |
13.5 |
| Exit pupil diameter (mm) |
50 |
50 |
| Distance of pupil |
9 |
9 |
| Eyepiece aperture（mm） |
+/-5 |
+/-5 |
| Battery type（v） |
The 1 section 3V lithium battery |
The 1 section 3V lithium battery |
| Battery life（h） |
40-50 |
40-50 |
| Operating temperature（℃） |
-40 /+50 |
-40 /+50 |
| Relative humidity |
5%-98% |
5%-98% |
| Impact resistance |
>800G |
>800G |
| Waterproof |
IP65/（IP67optinal） |
IP65/（IP67optinal） |
| Dimensions（mm） |
160x55x69(including eye mask) |
250x58x70(including eye mask) |
| Weight （g） |
295g(finished) |
338g(finished) |
