Product description：
The DT-NSCB adopts a high-performance super-second-generation image intensifier, and the special post-aiming device is designed, the aiming effect at night is good, the structure adopts a full-metal body, the mechanical strength is high, the structure is small, and the structure is easy to assemble and disassemble. And the white light aiming device is matched with the white light aiming device, so that a good viewing effect can be achieved at night. In the night vision mode, the night-field sniping can be performed as long as the conditions for the use of the micro-illumination of 10-3 lux (with weak glow) can be met. The invention has the advantages of small specific area, light weight, convenient use, reliable performance and high cost performance. In addition, that front-to-scan has the function of automatic light-proof protection, and is very suitable for city operation. independently controllable The infrared light-supplementing device completely satisfies the different service conditions of the army and the police.
Technical specifications:
| MODEL |
DT-NSCB1 |
DT-NSCB3 |
| Generation |
Gen 2+/Gen3(optional) |
Gen 2+/Gen3(optional) |
| Magnification |
0.85X |
2X |
| Resolution |
60-64 |
60-64 |
| Objective pupil |
22mm |
40mm |
| FOV(°) |
40 |
13.5 |
| Exit pupil diameter (mm) |
50 |
50 |
| Distance of pupil |
9 |
9 |
| Eyepiece aperture（mm） |
+/-5 |
+/-5 |
| Battery type（v） |
The 1 section 3V lithium battery |
The 1 section 3V lithium battery |
| Battery life（h） |
40-50 |
40-50 |
| Operating temperature（℃） |
-40 /+50 |
-40 /+50 |
| Relative humidity |
5%-98% |
5%-98% |
| Impact resistance |
>800G |
>800G |
| Waterproof |
IP65/（IP67optinal） |
IP65/（IP67optinal） |
| Dimensions（mm） |
160x55x69(including eye mask) |
250x58x70(including eye mask) |
| Weight （g） |
295g(finished) |
338g(finished) |
