Manufacturers Direct Sales of Multifunctional Cost-Effective Night Vision Instrument

Model: DTS-35

Send email to us

Technical specifications:

MODE	DTS-35
Generation	Gen 2+/Gen3(optional)
Magnification	1X
FOV(°)	50 +/-1(40 optional)
Automatic Brightness Control	YES
Bright Light Cut-off	YES
Infrared Illuminator	Built-in(850nm 20mW)
IR Indicator	YES
Low Battery Indicator	YES
Battery type	AA battery (AA x1) / CR123x4 Battery pack
Power supply	1.2-1.6V
Installation	Head mounted(standard American helmet interface)
Control mode	ON/IR/AUTO
Battery capacity	800-3200maH
Battery life	40-100H
Optical distortion	0.1% Max
Distance of pupil	20-45mm
Eyepiece aperture	9mm
Diopter adjustment	+ / - 5
Off-axis （mm）	5-10
Eye distance adjustment range	50-80mm
Operating temperature	-40--+55℃
Relative humidity	5%-95%
Waterproof	IP65/IP67
Dimensions	110x100x90
Weight	330g(housing)/480g(finished)
