Manufacturer Direct Sales Practical Strong Cost-Effective IP68 Night Vision

Model: DTS-35

Short Description:



  • The truly field of view 50-degree
  • Flip-Up On-Off, Side Flip-Up On-Off
  • The diopter can be adjusted -5/+5
  • no distortion , full screen clearly without distortion
  • the tender can be controled




Product Detail

Product Tags

a609dd9623c2b0b4948a6412f928432

Technical specifications:

MODE DTS-35
Generation Gen 2+/Gen3(optional)
Magnification 1X
FOV(°) 50 +/-1(40 optional)
Automatic Brightness Control YES
Bright Light Cut-off YES
Infrared Illuminator Built-in(850nm 20mW)
IR Indicator YES
Low Battery Indicator YES
Battery type AA battery (AA x1) / CR123x4 Battery pack
Power supply 1.2-1.6V
Installation Head mounted(standard American helmet interface)
Control mode ON/IR/AUTO
Battery capacity 800-3200maH
Battery life 40-100H
Optical distortion 0.1% Max
Distance of pupil 20-45mm
Eyepiece aperture 9mm
Diopter adjustment + / – 5
Off-axis  （mm） 5-10
Eye distance adjustment range 50-80mm
Operating temperature -40–+55℃
Relative humidity 5%-95%
Waterproof IP65/IP67
Dimensions 110x100x90
Weight 330g(housing)/480g(finished)
