Multifunctional Thermal Image DT-TW21
Technical specifications:
| Project | specification |
| Volume:mm | 88x38x70(Handheld) 88x38x82(Head-mounted) 88x43x78(Clip-on) |
| Weight:g(exclude battery) | 140(Handheld) 144(Head-mounted) 92(Clip-on) |
| Battery: | CR123A(1) / Battery pack |
| Battery life:H | 3.5-4.5 |
| Waterproofing grade | IP67 |
| Compatibility | PVS31 PVS14 NVG18 DTS31 DTS35 DTG18 DTNH9 DTS13 |
| Multifunction | Handheld Head-mounted Clip-on |
| Type of sensor | unrefrigerated long wave infrared thermal radiometer |
| Detector resolution | 384×288 |
| Applicable wavelength:um | 8-12um |
| Amplification factor: | X 1.2 (Handheld/Head-mounted) X 1.0 (Clip-on) |
| Field of view:FOV | 32degree(Clip-on) 36degree(Handheld/Head-mounted) Center of circle |
| Focal distance of objective: | fixed-focus |
| Objective aperture: | F1.0 |
| Luminance: | adjustable |
| Focussing distance: | 250mm~∞ |
| Image model: | White/black/green/red/Highlight/Outline |
